* Complete HART communicator included
* Optional Foundation Fieldbus communicator
* Modular re-rangeable and expandable concept
* Individual components can be used as stand-alone instruments
×
Introducing, the brand new Druck DPI 620G Multifunction Calibrator with HART, now available in stock! This versatile calibrator from the trusted brand HOBOY is a must-have tool for professionals in the field of calibration and measurement.
The Druck DPI 620G is a multifunction calibrator that is designed to provide precision and accuracy in calibrating a wide range of instruments. It is equipped with HART communication capabilities, allowing for seamless integration with HART-enabled devices for a more efficient calibration process.
This calibrator is packed with features that make it easy to use and highly reliable. It has a large, easy-to-read display that shows all the relevant information at a glance. The intuitive interface makes it simple to navigate through the various functions and settings.
One of the standout features of the Druck DPI 620G is its versatility. It can calibrate a variety of instruments, including pressure transmitters, temperature sensors, and flow meters. This means you can rely on this calibrator for all your calibration needs, saving you time and money.
In addition to its calibration capabilities, the Druck DPI 620G also offers advanced features such as data logging and remote control. With the ability to store and retrieve calibration data, you can easily track and monitor the performance of your instruments over time. The remote control feature allows you to operate the calibrator from a distance, making it even more convenient to use.
The Druck DPI 620G is built to withstand the rigors of daily use in industrial environments. It is ruggedly constructed and designed to withstand shock, vibration, and extreme temperatures. This ensures that you can rely on this calibrator to perform consistently, even in tough conditions.
The Druck DPI 620G Multifunction Calibrator with HART is a top-of-the-line tool that offers precision, reliability, and versatility. With its advanced features and durable construction, it is the ideal choice for professionals who demand the best in calibration equipment. Don't miss out on this brand new product from HOBOY - order yours today
GE Druck DPI 620G General Specification |
||
Processor and memory |
800 MHz ARM Cortex - A8 Processor 512 MB 800 MHz SDRAM 4GB Internal flash memory 8GB Removable microSD card - provided as standard - Accepts cards up to 32 GB |
|
Display |
Size: 110 mm (4.3 in) diagonal; 480 x 800 pixels LCD: Colour display with touch-screen Protected by 2mm toughened glass, impact tested in accordance with BS EN 61010-1:2010 - 0.5kg object from 1 meter |
|
File Viewers |
A Windows ® desktop is available for managing files, running third party applications and viewing simple images, Word documents, Excel spreadsheets, PDF files and PowerPoint files |
|
Languages |
English {Default}, Chinese, French, German, Italian, Portuguese, Russian, Spanish, Dutch, Japanese |
|
Operating temperature |
-10° to 50°C or 14° to 122°F |
|
Storage temperature |
-20° to 70°C or -4° to 158°F |
|
Ingress Protection |
IP55 |
|
Humidity |
0 to 90% RH Non condensing |
|
Shock / Vibration |
BS EN 61010-1:2010; MIL-PRF-28800F for Class II equipment, 1 m Drop Tested |
|
EMC |
Electromagnetic compatibility: BS EN 61326-1:2006 |
|
Electrical safety |
Electrical – BS EN 61010-1: 2010 |
|
Pressure safety |
Pressure Equipment Directive - Class: Sound Engineering Practice - SEP |
|
Approved |
CE Marked |
|
Size - L: W: H |
DPI 620 Genii only: 183 x114 x 42 mm or 7.2 x 4.5 x 1.7 in |
|
Weight |
DPI 620 Genii only: ≈ 575 g (1.3 lb) – battery included |
|
Power supply |
Lithium-Polymer battery (GE Part number : IO620-Battery); Capacity: 5040 mAh (minimum), 5280 mAh (typical); Nominal voltage: 3.7 V. Charge temperature: 0° to 40°C (32° to 104°F) Discharge temperature: -20° to 60°C or -4° to 140°F Note: For best battery performance, keep the temperature less than 60°C (140°F). Charge/discharge cycles: > 500 > 70% capacity |
|
Duration |
Measure functions (CH1): ≈ 12 hours continuous. Dual Function, mA measure (CH2): ≈ 7 hours - 24 V Source at 12 mA |
|
Connectivity |
USB Type A, USB Type Mini B |
|
