Infrared Temperature Range |
-40 to 1202°F (-40 to 650°C) |
Infrared Accuracy |
<32°F (0°C): ±(2.0°F (±1.0°C) + 0.1°/1°F or °C) >32°F (0°C): ±1% or ±2.0°F (±1.0°C), whichever is greater |
Display Resolution |
0.1°F (0.1°C) |
Infrared Spectral Response |
8 to 14 µm |
Infrared Response Time |
<500 msec |
Thermocouple Type-K Input Temperature Range |
-454 to 2501°F (-270 to 1372°C) |
Thermocouple Type-K Input Accuracy |
-454 to -40 (-270 to -40°C): ±(2°F + 0.2°/1°F) (±[1°C + 0.2°/1°C]) -40 to 2501.6°F (-40 to 1372°C): ±1% or 2°F (±1% or 1°C), whichever is greater |
Distance to Measurement Spot Size |
30:1 |
Laser Sighting |
Single-point laser <1 mw output Class 2 (II) operation, 630 to 670 nm |
Minimum Spot Size |
0.75" (19 mm) |
Emissivity Adjustment |
By built-in table of common materials or digitally adjustable from 0.10 to 1.00 by 0.01 |
Data Storage with Date/Time Stamp |
20 points |
PC Interface and Cable |
None |
Hi/Low Alarms |
Audible and two-color visual |
Min/Max/Avg/Dif |
Yes |
Display |
Dot matrix 98 x 96 pixels with function menus |
Backlight |
Two levels, normal and extra bright for darker environments |
Trigger Lock |
Yes |
Switchable Celsius and Fahrenheit |
Yes |
Power |
2 x AA/LR6 Batteries |
Battery Life |
Laser and backlight on, 12 hours (used continuously) Laser and backlight off, 100 hours (used continusously) |
Operating Temperature |
32 to 122°F (0 to 50°C) |
Storage Temperature |
-40 to 140°F (-20 to 60°C) |
Bead Thermocouple Type-K Range |
-40 to 500°F (-40 to 260°C) |
Bead Thermocouple Type-K Accuracy |
±2.0°F (1.1°C) from 32 to 500°F (0 to 260°C), typically within 2.0°F (1.1°C) from -40 to 32°F (-40 to 0°C) |
